The Shipdex™ Protocol applies to ASD S1000D™ issue 2.3 (www.s1000d.org).
The Shipdex™ Protocol stands for Business Rules and Technical Specifications to assure a high quality of technical and logistics data and the data exchange between Ship-owners, Shipyards, Manufacturers, Classification Societies and Application Service Providers. For Application Service Providers it is a basic specification to implement data interfaces from Technical Manuals Solutions to Maintenance and Purchase Systems.
The Shipdex™ Protocol covers technical data exchange in any sea project. This means that the Shipdex™ Protocol is open to every company/organization which wishes to adopt it.
Shipdex™ Protocol applies to the “ASD S1000D™ International Specification for technical publication utilizing a common source database” issue 2.3 to exchange data in a neutral and standardized format. This means that it can be implemented by anyone on different Information Technology systems. This feature, along with the concept of modularization, makes Shipdex™ Protocol acceptable to the international shipping community.
Information produced in accordance with Shipdex™ Protocol is achieved in a modular form, called a “data module”, which is defined as “the smallest self contained information unit within a Shipdex™ dataset”.
Shipdex™ Protocol defines data modules as containers for data exchange. The data module types that the Shipdex™ Protocol uses are:
All data modules that are applicable to the Product may be gathered and managed in a database, which is hereafter referred to as the Common Source Data Base (CSDB). Information is not duplicated in the CSDB although individual data modules can be used many times in the output. Savings are therefore made in the maintenance of the data in that it only needs to be changed once, whilst the changed information appears throughout the output.
The Shipdex™ Protocol specification criteria is to provide the final user with essential, complete and non-redundant technical information, whose main documentation contents are strictly linked to logistic studies (if any) or equivalent analysis and related maintenance strategies.
The documents contents are gathered in an organic way, with a different structure depending on the type of data dealt with, in Data Modules (DMs) that represent the macro-information components. Every Data Module corresponds to a specific, uniquely identified, electronic file produced with XML language, allowing to structure and identify every individual information contained in the DM itself.
Every Data Module contains data supplied in XML format and can refer:
